configuration¶

System configuration of various kind are the bridge between core4 development and operations activities. Key features of core4 configuration are:

to keep sensitive data safe and keep naive staff and smart hackers out.
to make the life of system administrators easy. The config system supports various configuration sources, e.g. configuration files, a central mongodb sys.conf collection, user configuration files, default values, OS environment variables as well as project specific config files. Administrators choose their weapons.
to make the life of data scientists and developers easy. The config system supports cross-database application development, local and remote sources, and a hierarchical connection configuration mechanic which speed up the most critical ingredient to efficient programming: data access.

sources of configuration¶

There are multiple places where core4 is looking for configuration.

The core4 configuration file core4.yaml, see standard configuration. This file provides standard values.
The project configuration file for project specific settings in [project]/[project].yaml. This file is part of the project repository and is considered to provide project specific default values.
The optional local configuration file. If the special environment variable CORE4_CONFIG locates an existing file, then this file is processed. If the variable is not defined, then the user file ~/core4/local.yaml is processed if it exists (local user configuration). If this file does not exist, then the local system configuration file /etc/core4/local.yaml is parsed if it exists. If none of these options apply, then local configuration is skipped.
The optional MongoDB configuration documents in collection sys.conf are processed if defined. If the MongoDB collection sys.conf is specified in any of the previous locations, then any existing keys/values are overwritten.
Environment variables CORE4_OPTION_foo__bar can be defined to set configuration values (see environment options and values).

If more than one source specifies a configuration key, then the last value wins. Local configuration takes precedence over standard core4 and project values. Collection sys.conf takes precedence over local configruation. Finally environment variables have the top most priority to set configuration values.

Note

Expected file extension for all YAML files is lower case .yaml.

This boils down to the configuration flow outlined in the following diagram:

Warning

Administrators and operators often take the application’s configuration file and copy&paste the whole content into the concrete system configuration file. This is not the intended mechanic of core4 configuration. The configuration sources described above represent a cascade. Specify only those configuration settings for your local setup which are different to the standard configuration as defined in core4 and project configuration. Use local configuration files or the MongoDB collection sys.conf for your specific settings.

configuration language and format¶

core4 configuration uses YAML as the configuration language (see http://yaml.org/) and the PyYaml Python package supporting YAML version 1.1.

YAML is a human-readable data serialization language using both Python-style indentation to indicate nesting, and a compact format that uses [] for lists and {} for maps.

YAML natively encodes scalars (such as strings, integers, floats and boolean), lists, and dictionaries. Lists and hashes can contain nested lists and hashes, forming a tree structure.

YAML parses the type of configuration values. All quoted values represent strings. Non-quoted values are parsed into integers, floats, booleans and dates. Use YAML default tags to explicitely define the value type (see for example http://sweetohm.net/article/introduction-yaml.en.html).

core4 implements a custom tag !connect to express database access. See for example an excerpt from core4.yaml standard configuration file:

sys:
  log: !connect mongodb://sys.log
  role: !connect mongodb://sys.role

Note

The YAML syntax only applies to file based configuration, i.e. the configuration file specified in the environment variable CORE4_CONFIG, the user configuration file as well as the system configuration file. All configuration specified by environment variables (CORE4_CONFIG_...) as well as the bodies in MongoDB collection sys.conf represent the configuration keys and values. Still the !connect tag is processed.

project configuration¶

All project configuration is wrapped in a dictionary with the key equal to the project name.

Example project configuration file test.yaml for project test:

username: peter
password: ~

To access the username and password use:

config.test.username == "peter"  # True
config.test.password is None  # True

DEFAULT values¶

The DEFAULT dictionary defines default keys/values. These default values are forwarded into all configuration dictionaries:

DEFAULT:
   mongo_database: core4
   mongo_url: mongodb://localhost:27017

sys:
   mongo_databaes: section1db

This YAML example implements the following configuration values:

config.mongo_database == "core4"  # True
config.mongo_url == "mongodb://localhost:27017"  # True
config.sys.mongo_database == "section1db"  # True
config.sys.mongo_url == config.mongo_url  # True
config.sys.mongo_url == "mongodb://localhost:27017"  # True

project configuration features a DEFAULT dictionary, too. The default keys and values defined in the project configuration apply to the project configuration only. Consequently, if a project key in a section is not defined, then the project default value applies if it is defined. If the project configuration does not define a default value and a standard value is defined, then this global default value is forwarded.

Note

The project configuration as well as local configuration can provide a DEFAULT dictionary, too.

local configuration¶

The local configuration is used to overwrite core4 standard and project configuration keys/values for your concrete system setup. You can only specify keys which are either present in core4 standard (core4.yaml) or project configuration. All other keys/values are silently ignored.

environment options and values¶

As an administrator you can enforce configuration option values by defining environment variables. The structure is:

CORE4_OPTION_[key]__[value]
CORE4_OPTION_[key]__[sub_key]__[value]

Note the double underscore characters separating the keys and the value. There can be multiple keys.

Parsing of environment variables uses the YAML default tags !!int, !!float, !!bool, !!timestamp, !!str to parse type information. Furthermore the custom !connect tag is available (see !connect tag).

Example:

CORE4_OPTION_logging__stderr="INFO"
CORE4_OPTION_logging__exception__capacity="!!int 5000"

Use ~ to set a value to None:

CORE4_OPTION_logging__stderr="~"

`!connect` tag¶

core4 configuration provides a special tag !connect to manage database connection settings. This tag parses authentication/hostname information, database and collection name.

A fully qualified connection string to a MongoDB database testdb, collection result at localhost, port 27017, authenticated with username user and password pwd is:

coll: !connect mongodb://user:pwd@localhost:27017/testdb/result

If no hostname is specified, then the connection URL is taken from variable mongo_url. If no database name is specified, then it is taken from variable mongo_database. Therefore, the following three examples all cascade to the same connection settings:

DEFAULT:
  mongo_url: mongodb://usr:pwd@localhost:27017
  mongo_database: test

section1:
    mongo_database: db
    result1: mongodb://usr:pwd@localhost:27017/db/result
    result2: mongodb://db/result
    result3: mongodb://result

Asynchronous versus synchronous database access¶

core4 uses both the pymongo and the motor MongoDB database access driver. The synchronous pymongo driver is used by the core4 job execution framework. The asynchronous motor driver is used in conjunction with tornado ioloop in the core4 web service API framework.

To simplify MongoDB database connection all core4 classes derived from CoreBase automatically request synchronous connection. All core4 classes derived from CoreRequestHandler connect asynchronous with motor.

The following snippet demonstrates the default synchronous database access with CoreBase:

>>> from core4.base.main import CoreBase
>>> b = CoreBase()
>>> b.config.sys.queue
!connect 'mongodb://sys.queue'
>>>
>>> b.config.sys.queue.concurr
False
>>> b.config.sys.queue.count_documents({})
7

You can programmatically change from synchronous to asynchronous access:

>>> b = CoreBase()
>>> b.config.sys.queue.concurr = True
>>> await b.config.sys.queue.count_documents({})
7

You can also use the explicit method .connect_async:

>>> b = CoreBase()
>>> b.config.sys.queue.connect_async()
>>> await b.config.sys.queue.count_documents({})

The following example demonstrates the default connection setting with CoreBaseHandler. This class is the parent class of CoreRequestHandler:

>>> from core4.api.v1.request.main import CoreBaseHandler
>>> base = CoreBaseHandler()
>>> base.config.sys.queue.concurr
True
>>> await base.config.sys.queue.count_documents({})
7

Note

There are certain connections within the core4 ReST API framework which use synchronous database connectivity. These are connections to collection sys.log and sys.event where core4 utilises special MongoDB features of write concern for performance reasons. For this special database access we to build on top of the asycnhronous ioloop feature.

MongoDB collection `sys.conf`¶

If you prefer to use a central MongoDB database collection to setup your system, then you will have to provide the connection string. The standard core4 configuration disables the sys.conf setting (see standard configuration).

Either setup a local configuration file like this:

sys:
  conf: !connect mongodb://hostname:port/database/collection

Beware to replace hostname, port, database and collection with your actual settings and provide credentials to access the database if necessary.

Alternatively you can define the environment variable CORE4_OPTION_sys__conf with the above connect statement:

CORE4_OPTION_sys__conf="!connect mongodb://hostname:port/database/collection"

configuration access¶

All classes based on CoreBase have configuration access via the self.config attribute. To access configuration options and values you can either use plain dictionary syntax as in self.config["mongo_database"] or by dot notation as in self.config.mongo_database.

example¶

core4 configuration principles are best described by example. In this scenario a project has been created for an project named project1. As part of the automation workflow for this project some 3rd party web API is used to download data on a regular basis. The project configuration is supposed to provide API authorisation data, the URL for the web service as well as the target database and collection to store the downloaded data.

Therefore the project developer has created a dictionary api in the project configuration file project1.yaml located in the package directory. Furthermore the developer directs all database access to the default database for this project db1:

# file: project1/project1.yaml

DEFAULT:
  mongo_database: db1
api:
  url: https://example.org/api/v1/download
  username: prod-user
  password: ~  # to be defined by local setup
  download_collection: !connect mongodb://download

Since the project configuration is version controlled and part of the code repository, the developer provides the (default) API user, but no sensitive data, e.g. the API password.

During development of the project, the developer works with the following user configuration file located at ~/core4/local.yaml:

# file: ~/core4/local.yaml

DEFAULT:
  mongo_url: mongodb://localhost:27017

project1:
  api:
    username: test-user
    password: 123456

This setup allows the developer to use his or her test-user with valid credentials during implementation and to address the local MongoDB instance at mongodb://localhost:27017/db1/download. Please note that the hostname/port comes from ~/core4/local.yaml` while the database ``db1 and the collection download comes from the project configuration in project1.yaml.

After implementation is complete and during deployment the operator extends core4 system configuration in production located at /etc/core4/local.yaml with:

# file: /etc/core4/local.yaml (excerpt)

DEFAULT:
  mongo_url = mongodb://core:mongosecret@mongodb.prod:27017

project1:
  api:
    password: secret

This production setup provides actual credentials for the (default) API user prod-user and the production database located on server mongodb.prod.

The fully qualified download collection now points to mongodb://core:mongosecret@mongodb.prod:27017/db1/download

After several weeks with downloaded data the need arises to aggregate the data into a reporting collection. The developer, who has read-only access grants at mongodb.prod (username pete, password mysecret) extends the project configuration project1.py with:

# file: project1/project1.yaml

DEFAULT:
  mongo_database: db1
api:
  url: https://example.org/api/v1/download
  username: prod-user
  password: ~  # to be defined by local setup
  download_collection: !connect mongodb://download
  report_collection: !connect mongodb://report

To facilitate implementation activities and to work with actual production data the developer extends his ~/core4/local.yaml to read (only) the downloaded data from production with:

# file: ~/core4/local.yaml

DEFAULT:
  mongo_url: mongodb://localhost:27017

project1:
  api:
    username: test-user
    password: 123456
    download_collection: connect mongodb://pete:mysecret@mongodb.prod/db1/data

Now the report collection addresses mongodb://localhost:27017/db1/report with hostname/port coming from local.yaml and database and collection coming from project.yaml. The developer can read-only access production data by overwriting download_collection in his local.yaml.

This example show, how to create valid project configuration settings which can be overwritten easily for development as well as production needs. With the !connect tag the developer furthermore can easily create cross database connections which simplifies implementation activities if the developer has for example read-only access to production data.

All configuration files - project1.yaml, ~/core4/local.yaml and /etc/core4/local.yaml in this example - can be created and maintained independent of each other.
